Round Pilot Light Indicator Assembly - NEMA 4-12-4X - Red - 716-028-FS-XXX
Round Pilot Light Indicator Assembly - NEMA 4-12-4X - Red - 716-028-FS-XXX
$101.00
Our new studless red indicator lamp assembly fits in a 7/8” hole and requires no studs to mount. Available lamped with 6V, 12V, 24V, 48V, 110V or 220V. Let us know what marking you need when ordering.
Estimated Lead Time: Depends On Marking and Quantity Required
Voltage:
Quantity:
Specifications
Material: Acrylic & Nylon, Lamp Base is Die Cast
Mounts In Hole Size: 7/8” inches or 22 mm
Fastening Methods: Stud-less Design
Specify Marking Required: This is a thermal wax printed clear label and secured to inner lens
Current Rating: 20 mA
Lamp Type: LED
Operating Voltage: See Options
Life: 100,000 Hours
Rated: NEMA 4/12/4X
Terminal Capacity: Min. 20 AWG, Maximum 2x16 AWG
